GYS Electrode welding machine GYSARC 220 FV CEL with accessories 10-220 A
Electrode welding machine GYSARC 220 FV CEL with accessories 10-220 A
PRODUCT DESCRIPTION
Property and area of application: Single-phase E-Hand (MMA) welding current source with inverter technology
– For rutile, basic and cellulose electrodes up to diam. 5 mm
– MMA pulse
– Optional TIG pulse lift welding with direct current
– HOT START
– ARC FORCE
– ANTISTICK Further technical information:
– Width: 210mm
– Length: 420mm
– Welding voltage: 28.8V
– Ignition type: Contact ignition
– Weight: 10.5kg
– Protection class: IP23
– Insulant class: PROTEC 400
– Type: With accessories
– Operating voltage: 85-265V
– Height: 350mm
– Mains voltage: 230 V / 50/60 Hz
– Current consumption: 16A
– Fuse: 16A
– Power input: 12.5kVA Scope of supply: Electrode welding machine, 3 m ground cable, pre-assembled, 3 m electrode holder, pre-assembled
Welding current range: 10-220 A
Welding current at 60% ED/40°C: 130 A
Welding current at 100% ED/40°C: 100 A
Standard: EN 60974-1
Connector type: F
Brand: GYS
Scope of delivery:
1,00 ST Electrode welding machine GYSARC 220 FV CEL with accessories 10-220 A
