BENNING Device tester ST 710 2500 test units /with tester/test cable L270xW115xH55mm

Login to see prices

SKU:4014650503084

For safety testing of electrical equipment/work equipment, e.g. power tools, motor equipment, luminaires, extension lines, domestic appliances according to DIN VDE 0701/0702 DGUV regulation 3
– Simple operation via three buttons
– The complete test can be performed within 10 s independently of the network
– Automatic test sequence for devices of Class I, II (III)
– Measurement of insulation resistance, protective conductor resistance, protective conductor and contact current according to equivalent leakage current method
– Lead test including RPE and RISO
– Continuity and short circuit test of the phase/neutral conductor
– Voltage at external socket with earthing contact (L-N, L-PE, N-PE)
– Three-phase test specimens can be tested by means of optional measurement adapter (measurement adapter not included)
– Limits according to VDE standard pre-set Particular benefits: Graphic display, automatic test routine with good/bad result, battery capacity for 2,500 test objects, test protocols (Excel, PDF) are free to download at www.benning.de Further technical information:
– Width: 115mm
– Length: 270mm
– Height: 55mm Scope of supply: Device tester ST 710, carry bag, test cable with alligator clip, IEC power cord, batteries (6 x type AA)
– For replacement batteries see article no. 4000 901 811 Optional accessories (not included in the scope of supply): 300 test badges (see article no. 4000 828 886) Measurement adapter CEE plug with earthing contact with 16 A / 32 A (see article no. 4000 828 901 / 4000 828 902) BENNING CM 9-1 leakage current clamp (see article no. 4000 828 949) Note on the disposal of batteries and rechargeable batteries As we sell batteries and rechargeable batteries and devices that contain batteries and rechargeable batteries, under the German Battery Act (BattG we are obliged to draw your attention to the following: The symbol of the waste bin with the X through it on batteries and rechargeable batteries means that they must not be disposed on in household waste after consumption. If batteries or rechargeable batteries contain mercury, cadmium or lead, you will find the chemical symbol (Hg, Cd or Pb) under the symbol of the waste bin with the X through it. Every user of batteries or rechargeable batteries is legally obliged to return old batteries and rechargeable batteries. They can be returned, free of charge, to the retailer or another collection point near you. You can obtain the addresses of suitable collection points near you from your local government authority. In the case of batteries that contain more than 0.0005 percent by mass mercury, more than 0.002 percent by mass cadmium or more than 0.004 percent by mass lead, the chemical symbols of the respective harmful substance used are indicated under the waste bin symbol. The chemical symbols have the following meaning: Pb: Battery contains lead Cd: Battery contains cadmium Hg: Battery contains mercury
