GEDORE Torque multiplier DVV-40Z 4000 Nm 1 inch al. w.offset reaction arm Z-shape
1,00 ST Torque multiplier DVV-40Z 4000 Nm 1 inch al. w.offset reaction arm Z-shape
PRODUCT DESCRIPTION
Mechanical, hand-operated torque multiplier for controlled fastener tightening and loosening
– Double-stage epicyclic gear
– Housing made of high-performance aluminium
– Model 4000 881 693 with non-return system for more efficient and safer use
– With non-destructive “Slipper” overload safety device to protect gear
– Clockwise and anti-clockwise ratcheting
– With offset Z-shaped reaction arm made of forged chromium-vanadium steel
– Optional retrofit with straight L-shaped reaction arm with adjustable lightweight metal reaction square (4000 881 694, not included in scope of supply)
– Accuracy: Better than +/- 3 % tolerance
– For use with a torque spanner (not included in scope of supply)
– Drive square with bore for impact wrench sockets with locking pin and O-ring Further technical information:
– Max. output lbf.ft: 2390lbf.ft
– Transmission ratio: 1:16
– Max. input lbf.ft: 220lbf.ft
– Subject to audit: Yes Supplied with sturdy transport case with foam insert, factory calibration certificate and settings table
Max. input N.m: 300 Nm
External square drive mm: 25 mm
Internal square drive: 1/2
Brand: GEDORE
External square drive: 1
Internal square drive mm: 12.5 mm
Scope of delivery:
1,00 ST Torque multiplier DVV-40Z 4000 Nm 1 inch al. w.offset reaction arm Z-shape
