PROMAT Drill groove milling cutter DIN 327 D type N nominal diameter 8 mm HSS-Co8 TiCN DIN 1835 B no. of cutters 2 short

HSS-Co8
– DIN 327 D
– Type N
– Two-flute cutter
– Short
– Centre cut
– Straight shank with pulling face
– Right-hand cutting
– For the milling of materials with small and medium strength to approx. 800 N/mm², with uncoated tool and 1,000 N/mm² with coated tool
– For milling narrow and form-fitting clearances as well as feather key grooves with greater depth Further technical information:
– Material qualification INOX stainless steel: Very suitable
– Material qualification cast: Very suitable
– Material qualification steel: Very suitable
– Shape: D
– Material qualification of special alloys: Somewhat suitable
– Shank Ø: 10mm
– Material qualification NF metals: Somewhat suitable
– Free grinding: 7,5mm
