PROMAT Drill groove milling cutter DIN 327 type N nominal diameter 10 mm HSS-Co8 DIN 1835 B no. of cutters 3 short
Sale ends in:
Drill groove milling cutter DIN 327 type N nominal diameter 10 mm HSS-Co8 DIN 1835 B no. of cutters 3 short
Drill groove milling cutter DIN 327 type N
PRODUCT DESCRIPTION
HSS-Co8
– DIN 327
– Type N
– Three-flute cutter
– Short
– Centre cut
– Straight shank with pulling face
– Right-hand cutting
– For milling low- and medium strength materials up to approx. 800 N/mm²
– For milling feather key grooves with greater depth for face and circumferential milling Further technical information:
– Material qualification INOX stainless steel: Somewhat suitable
– Material qualification cast: Very suitable
– Material qualification steel: Very suitable
– Shank Ø: 10mm
– Material qualification NF metals: Somewhat suitable
– Free grinding: 9,5mm
Coating: Uncoated
Nominal Ø: 10 mm
Length of cutting edge: 13 mm
Overall length: 63 mm
Length of insert: 21 mm
No. of cutters: 3
Shank design: DIN 1835 B
Type: N
Standard: DIN 327
Cutting materia
Scope of delivery:
1,00 ST Drill groove milling cutter DIN 327 type N nominal diameter 10 mm HSS-Co8 DIN 1835 B no. of cutters 3 short
Nominal Ø: 10 mm
Length of cutting edge: 13 mm
Overall length: 63 mm
Length of insert: 21 mm
No. of cutters: 3
Shank design: DIN 1835 B
Type: N
Standard: DIN 327
Cutting materia
Scope of delivery:
1,00 ST Drill groove milling cutter DIN 327 type N nominal diameter 10 mm HSS-Co8 DIN 1835 B no. of cutters 3 short
