Robert Bosch Power Tools GmbH Nibbler GNA 3,5
Sale ends in:
Nibbler GNA 3,5
Nibbler GNA 3,5
PRODUCT DESCRIPTION
Nibbler GNA 3,5, The corded GNA 3-5 Professional is Bosch´s strongest nibbler in the 620 W category, and is ideal for deep cuts. Clean cutting is enabled by its high torque motor and a reduced stroke rate. It is perfect for cutting various metal materials of up to 3.5 mm and is excellent for inner cutouts. Hex key WAF 4 (1 907 950 005); Auxiliary handle (2 602 025 075); Die plate (2 608 639 026); Punch (2 608 639 025); Supporting arm (2 607 001 190)
Article ID: 0601533103
ADDITIONAL INFORMATION
Packaging dimensions (width): 200 mm
Packaging dimensions (length): 348 mm
Packaging dimensions (height): 100 mm
Packaging dimensions (width x length x height): 200 x 348 x 100 mm
Material that can be processed: Steel up to 400 N/mm² at 3.5 mm
Cutting track width: 6 mm
Pre-drilling for interior cut-outs: 41 mm
Smallest radius: 70 mm
Stroke rate under load: 670 spm
No-load stroke rate: 1.000 spm
Weight: 3,5 kg
Tool dimensions (length): 292 mm
Tool dimensions (height): 117 mm
Cutting capacity in steel (400 N/mm²), max.: 3,5 mm
Cutting capacity in steel (600 N/mm²), max.: 2,4 mm
Cutting capacity in steel (800 N/mm²), max.: 1,6 mm
Cutting capacity in aluminium (200 N/mm²), max.: 4,0 mm
Rated input power: 620 W
Power output: 340 W
Vibration emission value ah [Cutting sheet metal]: 7,0 m/s²
Uncertainty K [Cutting sheet metal]: 1,5 m/s²
Product category subdivision: Nibbler
Positioning: Bosch's strongest nibbler for deep cuts in the 620 W category
User benefit incl. Reason to believe: High torque motor and a reduced stroke rate enable clean cuts
User benefit incl. Reason to believe: Perfect for cutting various metal materials of up to 3.5 mm
User benefit incl. Reason to believe: Excellent for inner cutouts
Positioning (BE): The most powerful model from Bosch
User benefit incl. Reason to believe (BE): High-torque 620 W motor
User benefit incl. Reason to believe (BE): Particularly suitable for distortion-free cutting of alloyed steels and stainless steel sheet
User benefit incl. Reason to believe (BE): Working to scribe mark and template easily possible
Title: Nibbler GNA 3,5 Professional
Novelty: no
Scope of supply: Hex key WAF 4 (1 907 950 005)
Scope of supply: Auxiliary handle (2 602 025 075)
Scope of supply: Die plate (2 608 639 026)
Scope of supply: Punch (2 608 639 025)
Scope of supply: Supporting arm (2 607 001 190)
SOL Date: 18.07.2002
Scope of delivery:
1 ST Nibbler GNA 3,5
Packaging dimensions (length): 348 mm
Packaging dimensions (height): 100 mm
Packaging dimensions (width x length x height): 200 x 348 x 100 mm
Material that can be processed: Steel up to 400 N/mm² at 3.5 mm
Cutting track width: 6 mm
Pre-drilling for interior cut-outs: 41 mm
Smallest radius: 70 mm
Stroke rate under load: 670 spm
No-load stroke rate: 1.000 spm
Weight: 3,5 kg
Tool dimensions (length): 292 mm
Tool dimensions (height): 117 mm
Cutting capacity in steel (400 N/mm²), max.: 3,5 mm
Cutting capacity in steel (600 N/mm²), max.: 2,4 mm
Cutting capacity in steel (800 N/mm²), max.: 1,6 mm
Cutting capacity in aluminium (200 N/mm²), max.: 4,0 mm
Rated input power: 620 W
Power output: 340 W
Vibration emission value ah [Cutting sheet metal]: 7,0 m/s²
Uncertainty K [Cutting sheet metal]: 1,5 m/s²
Product category subdivision: Nibbler
Positioning: Bosch's strongest nibbler for deep cuts in the 620 W category
User benefit incl. Reason to believe: High torque motor and a reduced stroke rate enable clean cuts
User benefit incl. Reason to believe: Perfect for cutting various metal materials of up to 3.5 mm
User benefit incl. Reason to believe: Excellent for inner cutouts
Positioning (BE): The most powerful model from Bosch
User benefit incl. Reason to believe (BE): High-torque 620 W motor
User benefit incl. Reason to believe (BE): Particularly suitable for distortion-free cutting of alloyed steels and stainless steel sheet
User benefit incl. Reason to believe (BE): Working to scribe mark and template easily possible
Title: Nibbler GNA 3,5 Professional
Novelty: no
Scope of supply: Hex key WAF 4 (1 907 950 005)
Scope of supply: Auxiliary handle (2 602 025 075)
Scope of supply: Die plate (2 608 639 026)
Scope of supply: Punch (2 608 639 025)
Scope of supply: Supporting arm (2 607 001 190)
SOL Date: 18.07.2002
Scope of delivery:
1 ST Nibbler GNA 3,5
